SMART RESOLVER POSITIONER OF PNEUMATIC ACTUATORS SPIROSTER-07

Download documentation files Manual_Spiroster.pdf

Parameters Supply pressure 140-800 kPa Flow capacity Up to 300 l/min Mass 900 g Driving signal 4-20 mA Voltage drop on input 10,5 V Analog feedback signal 4-20 mA Feedback signal voltage 12-36 VDC Signals of extreme positions 24-48 V DC, 12 mA voltage drop 2 V at the most Range of insensibility 0,1% Mounting position Any Protection class IP 67 Operating temperature -20 ÷ +70°C   Description Spiroster-07 is designed to mount on single-acting pneumatic actuators with pressure input up to 800 kPa. Positioner can not be installed in places running the risk of explosion. Environmental conditions can not exceed these mentioned in nominal data.
